Compliance standard :

IS 7182‑1973

Application :

The test is required for assessing the functional quality of aluminum collapsible Tubes.

Details specification :

• A standard load is allowed to fall on the empty tube and the resistance offered to this load is measured.
• Designed For tube of diameter  : 13.5mm
• Grooving radius              : 32 mm
• Grooving Depth              : 5 ± 0.2 mm
• Distance b/w stopper & shutter  : 32 mm
• Shutter weight               : 70 ± 1 Gram
• The auxiliary base plate is to be inserted in the apparatus.
• Complete with stand, shutter mechanism and scale.
