PROPORTIONAL CALIPER
None
FIXED POINT
- TWO FIXED POST
- FOUR FIXED POST
-
More Information
-
Technical specification
-
Accessories
-
Spares
More Information
Complies with following International Standards:
ASTM D4791
Purpose:
Used for rapid and easy determination of the percentages of flat particles, elongated particles, or flat and
elongated particles in coarse aggregates
Significance & Use:
Individual particles of aggregate of specific sieve sizes are measured to determine the ratios of width to thickness, length to width, or length to thickness.
Construction Details:
- Manufactured from corrosive resistant plated steel.
- Consists of a base plate with two vertical fixed posts, Rubber feet and a swinging arm mounted between them so that the openings between the arms and the posts maintain a constant ratio.
- The axis position can be adjusted to provide the desired ratio of opening dimensions I.g. 1:2, 1:3, 1:4, and 1:5.
- The length of the pivoting arm will be 13 inches (330mm) in dimension as per ASTM D4791
- The size of the base plate will be 6 x 16 inches (152 x 406 mm) in dimensions.
- Weight : 3.0 KG
Technical specification
PROPORTIONAL CALIPER - TWO FIXED POST - ASTM D4791
|
Overall Dimensions in Inches (L x W x H) |
16 X 8.5 X 4 |
|
Weight (Approx.) |
8 Kgs Approx. |
