MORTAR MIXER-4.75 LITERS- IS 10890

MORTAR MIXER-4.75 LITERS- IS 10890

Model Number : TM-121

As per IS:10890.00. The instrument is specially designed to prepare cement mortar for Strength Determination. It is used for mixing cement pastes, mortars and pozzolanas. It can also be used for uniform mixing of soils with additives such as lime, cement, etc.

  • More Information
  • Technical specification
  • Accessories
  • Spares
More Information
up-botton

Compliance with following International Standards:

EN 196‑1 & EN 196‑3, IS : 4031, IS 10890, IS : 1727, ASTM C451


Construction details:

  1. Compact and tactful design
  2. Aesthetic Appearance
  3. Exterior body powder coated in attractive shades
  4. Paddle and bowl made of Stainless Steel Material
  5. An epicyclical type stainless steel paddle imparts both planetary and revolving motion.
  6. Stainless steel bowl is fitted with heat resistant handle
  7. Stainless Steel Handle is fitted with lid made of non‑absorbing material and is not attacked by cement, masonry cement, cement pozzolana mixture or lime pozzolana mixture.
  8. The blade is about 75 mm long, 50 mm wide and tapered to a thin edge.
  9. Mixer operates on two different speeds. Mixer blade has low speed of (140 ± 5 rpm) and medium speed of (285 ± 10 rpm).
  10. It also has a planetary movement of (62 ± 5 rpm) in low range and planetary movement of (125 ± 10 rpm) in medium range.
  11. The mixing paddle has a planetary motion and is driven by a motor
  12. The scraper consists of semi rigid rubber blade attached to a handle about 150 mm long.
  13. Suitable for operation on 230 Volts, 50 Hz, single phase, AC Supply


Technical specification
up-botton
MORTAR MIXER-4.75 LITERS- IS 10890

Overall Dimensions

450 X 510 X 920 (L X W X D) mm

Capacity

4.75 liters approx

Beater blade

111 mm

Vessel Dimensions

160 mm Dia x 130 mm H

Operation on

230 Volts, 50 Hz, Single Phase, AC Supply

Weight (Approx.)

62 Kg


Accessories
up-botton
Spares
up-botton
