WET SIEVING APPARATUS (FINENESS OF FLY ASH TESTING APPARATUS) - (ASTM C430)

Applications:

Wet Sieving Apparatus is used for determining the fineness of fly ash.

Details:

The apparatus comprises of following parts and accessories

1. A special stainless steel sieve, 0.045 mm opening, No.325 stainless steel wire cloth. The frame is 2 inches (50.8 mm) diameter, and 3 inches (76.2 mm) deep from rim to cloth.
2. A spray nozzle Ø 17.5 mm diameter with 17 holes, Ø 0.5 mm oriented and spaced to conform to the standards.
3. Supplied complete with a pressure gauge of Ø 80 mm diameter and fittings for connection to the water supply.
