Applications:

B.O.D. Incubators are used to provide temperature conditions for Bio‑Oxygen Demand test for cells / tissue culture / bacteria micro‑organism culture application, raw material and bulk product storage, plasma and blood product storage, serum incubation, immunological studies and other applications in the field of research, development, production and quality control.

EIE incubators are majorly used for Media Preparation & Culture growth at temperatures of 22.5 °C ± 2.5 °C & 32.5 °C ± 2.5 °C in Microbiology or ARD labs across the world.

Salient Features:

1. Exterior boy is fabricated from S.S. 304 Material
2. Interior chamber is also fabricated from Mirror polished Stainless Steel S.S. ‑ 316 Material
3. Outer double walled metal door with sponge ‑ type silicon gasket for air‑tight sealing as to avoid leakage of chamber uniformity
4. Electrical wiring as per CE Compliances ‑ with individual numbering of each internal circuitry wire for ease of maintenance & Repairing
5. Chamber illumination is accomplished by Fluorescent light with door switch.
6. Cord wire duly tested and inspected with stress factor as per CE standard
7. Electric Motor of blower located at the back side of unit, which is protected with safety cover to avoid accident
8. Standard motor of reputed companies ‑ such as CG, GODREJ or GE Make
9. User friendly and tactfully designed chamber door and locking mechanism
10. Aesthetic outer appearance and high quality
11. Unit mounted on castor wheels for easy movement.
12. Supplied complete with Stainless Steel Trays for sample placement
13. Supplied complete IQ, OQ, PQ, DQ Documentation and instruction manual. (Only For Pharmaceutical industries)

Air Circulation:

Temperature is maintained by a quiet running blower for better air circulation throughout the chamber. Forced air circulated vertically down and re‑circulated throughout the chamber for uniform temperature distribution.

Heating & Cooling System:

Long lasting U‑Shaped tubular heaters used as heating element. Hermetically sealed compressor CFC free compressor (134 A gas) coupled with evaporation coil and condenser.

Trays for samples:

1. Removable wiremess trays are part of the standard supply.
2. Strong enough to with‑stand heavy load of test specimens, which should be equally distributed among trays.
3. Such trays will also facilitate better air circulation.
4. The distance between trays will be 15‑20 centimeters.

Safety Features:

1. High temperature safety cut off (Thermostat)
2. Electrical overload safety (Fuse 10 Amperes)
3. Time delay for compressor switch ON

Pre installation mandatory requirement : (Guarantee void in case of non compliance):

1. An operator shall maintain Room temperature around machine preferably at 25 °C with air conditioning system or shall arrange for a well ventilated room with exhaust fan. However, surrounding temperature should not exceed 30 °C .
2. Stabilized Input Voltage of 230 Volt, 50 Hz, 20 Amps, AC Supply must be available for error less performance of the instrument. Use of Servo Controlled Stabilizer is recommended.
