ASPHALTNESS EXTRACTION TEST APPARATUS-(ASTM D6560)
Model Number : EIE-PTLT-144
-
More Information
-
Technical specification
-
Accessories
-
Spares
More Information
Compliance Standards:
ASTM D6560, IP 143, BS 2000 (Part 143)
Applications:
- Determines the amount of wax free material insoluble in n-heptane, but soluble in hot toluene
- Applicable for gas oil, diesel fuel, fuel oil, lubricating oil, bitumen, and crude petroleum, which has been topped up to an oil temperature of 260°C
- Comprises condenser, extractor, stoppers, stirrer, funnel and evaporation dish
- Temp. range : ambient to 100°C (Evaporation Bath)
- Tank capacity : 6 liters
- Voltage : 220 volts, 50 Hz, Single phase, AC Supply
- Power : 1.5 kW
- Weight : 10kg
- Complete with CLAMP & BOSSHEAD, for fitting clamp to stand.
Essential Accessories available at extra cost:
1) Digital Stopwatch @ Rs 550
2) Analytical balance 220 gram x 0.1 mg @ Rs 55000
3) Desiccators 200mm @ Rs 3050
Technical specification
ASPHALTNESS EXTRACTION TEST APPARATUS-ASTM D6560
Overall Dimensions in Inches (L x W x H) |
8 X 12 X 36 |
Weight [kg] |
8 KG |
