U.V. SPECTROPHOTOMETER FOR WEBSITE

U.V. Spectrophotometer

Model Number : 2375E

None

U.V. SPECTROPHOTOMETER VARIETY
  • SINGLE BEAM
  • DOUBLE BEAM
MODEL
  • 371E
  • 1371E
  • 2371E
  • 2373E
  • 2375E
  • 2377E
  • 3375E
Add to Cart
  • More Information
  • Technical specification
  • Accessories
  • Spares
More Information
up-botton

Microcontroller based instrument having range 190-1100mm,on screen standard curve display on large 5 inches graphics LCD, 1.0 nm Spectral Bandwidth, 1200 Lines/mm Grating, 8 position auto cell changer, Wavelength Scanning, PC connectivity using parallel port interface. It has facility for WL Scan, Kinetics, Multi Wavelength  & DNA/ Protein models, inclusive of PC Software.

Salient features:
  • Double Beam Optics
  • Large 5 Inch Graphical Display
  • Auto Wavelength Setting
  • On-Screen Curve Display
  • Tungsten/Deuterium Lamp can be turned ON/OFF individually to Extend Lifetime
  • Application Software provides complete control of the Instrument from a Computer through the built-in USB Port
  • Basic, Wavelength Scan, Multi-Wavelength, Quantitative, DNA/Protein modes
  • Pre-Aligned design makes it convenient to change Lamps
  • Large Sample Compartment, can accommodate 5 - 100 mm path-length cuvettes with optional holders. 8-Position Auto Cell Changer of 10 mm path-length provided.
 Accessories:
  • Quartz Cuvettes - A set of 2,
  • Glass Cuvettes - A set of 4
  • Mains Lead,
  • Operation Manual
  • Dust Cover

Technical specification
up-botton

Modes

Basic, Wavelength Scan, Multi-Wavelength Kinetics, Quantitative, DNA/Protein

Wavelength Range

190 - 1100 nm

Spectral Bandwidth

1.0 nm

Optical System

Double Beam, Grating 1200 lines/mm

Wavelength Accuracy

± 0.3 nm

Wavelength Repeatability

± 0.2 nm

Scanning Speed

HI, MED, LOW, MAX. 3000 nm/min

Photometric Accuracy

± 0.3 %T or ± 0.002 A/h @ 1A

Photometric Range

0 - 200 %T, -0.3 to 3A, 0 - 9999 Conc.

Stray Light

< 0.05 %T @ 220, 340 nm

Stability

± 0.001 A/h @ 500 nm

Display

5 inches Graphic LCD (320 x 240 dots)

Baseline Flatness

± 0.001A/h (200 - 1000 nm)

Sample Compartment

Standard 8 cell with automatic cell changer, 10 mm path-length, (50 & 100 mm path length optional at extra cost)

Light Source

Halogen and Deuterium lamps (Pre-Aligned)

Printer Interface

USB Port for PC connectivity

Power

230 Volt ± 10% AC,50 Hz, AC Supply

Dimensions(L x B x H)

Instrument: 590 x 455 x 250 mm (Approx.) Box: 650 x 535 x 335 mm (Approx.)

Weight

Instrument: 17.5 Kg (Approx.) Box: 20 Kg (Approx.)
