B.O.D. INCUBATOR

B.O.D. INCUBATOR

B.O.D INCUBATOR SIZE (H X W X D)
  • 30 X 30 X 30 CM
  • 45 X 45 X 45 CM
  • 70 X 50 X 50 CM
  • 60 X 60 X 60 CM
  • 90 X 60 X 60 CM
  • 125 X 60 X 60 CM
  • 125 X 70 X 70 CM
  • 125 X 80 X 80 CM
  • 125 X 90 X 90 CM
MATERIAL OF CONSTRUCTION
  • INNER S.S.
  • COMPLETE S.S.(GMP)
Add to Cart
  • More Information
  • Technical specification
  • Accessories
  • Spares
More Information
up-botton

Salient Features:

  1. Exterior boy is fabricated from Mild Steel material, which is powder coated in attractive shades.
  2. Interior chamber is also fabricated from Mirror polished Stainless Steel S.S. ‑ 304 Material
  3. Outer double walled metal door with sponge ‑ type silicon gasket for air‑tight sealing as to avoid leakage of chamber uniformity
  4. Electrical wiring as per CE Compliances ‑ with individual numbering of each internal circuitry wire for ease of maintenance & Repairing
  5. Chamber illumination is accomplished by Fluorescent light with door switch.
  6. Cord wire duly tested and inspected with stress factor as per CE standard
  7. Electric Motor of blower located at the back side of unit, which is protected with safety cover to avoid accident
  8. Standard motor of reputed companies ‑ such as CG, GODREJ or GE Make
  9. User friendly and tactfully designed chamber door and locking mechanism
  10. Aesthetic outer appearance and high quality
  11. Unit mounted on castor wheels for easy movement.
  12. Supplied with instruction Manual & Circuit Diagram
  13. IQ, OQ, PQ at extra cost.


Air Circulation:

Temperature is maintained by a quiet running blower for better air circulation throughout the chamber. Forced air circulated vertically down and re circulated throughout the chamber for uniform temperature distribution.


Heating & Cooling System:

Long lasting U Shaped tubular heaters used as heating element. Hermetically sealed compressor CFC free compressor (134 A gas) coupled with evaporation coil and condenser.


Trays for samples:

  1. Removable wire mess trays are part of the standard supply.
  2. Strong enough to with‑stand heavy load of test specimens, which should be equally distributed among trays.
  3. Such trays will also facilitate better air circulation.
  4. The distance between trays will be 15‑20 centimeters.


Safety Features:

  1. High temperature safety cut off (Thermostat)
  2. Electrical overload safety (Fuse 10 Amperes)
  3. Time delay for compressor switch ON


Pre installation mandatory requirement : (Guarantee void in case of non compliance):

  1. An operator shall maintain Room temperature around machine preferably at 25 °C with air conditioning system or shall arrange for a well ventilated room with exhaust fan. However, surrounding temperature should not exceed 30 °C .
  2. Stabilized Input Voltage of 230 Volt, 50 Hz, 20 Amps, AC Supply must be available for error less performance of the instrument. Use of Servo Controlled Stabilizer is recommended.
