DETERMINATION OF MOISTURE EXPANSION USING BOILING WATER FOR UNGLAZED TILE-(BIS 13630-3, EN ISO 10545-10) WITH ACCESSORIES
Model Number : TC-111A
As per IS:13630 (Part 3). Complete with Digital Vernier Caliper 300 mm, Dessicator of 300 mm dia, Length Comparator with standard reference bar and 1 kg silica gel. Detail Specification as per following page.
-
More Information
-
Technical specification
-
Accessories
-
Spares
More Information
Complies with International Standards:
EN ISO 10545-10, IS 13630 (Part-3)
Purpose:
For moisture expansion test of ceramic tiles. The tiles will be Immersed in boiling water for 24 h consecutively, ensuring that there is at least 50 mm height of water above and the test specimen do not touch each other or touch the base and sides.
Salient Features:
- Double walled in construction
- Inner chamber and lid made of mirror polished Stainless Steel material .
- Exterior body is made of Mild steel material which is powder coated in attractive shades.
- The gap between the inner chamber and exterior body is filled with high grade glass wool to minimize the thermal heat loss.
- The heating mechanism comprises of set of heaters pertaining to fast heating
- Supplied with stand made from strong S.S. rod to place ceramic tiles.
- This stand will be removable.
- The machine will also be supplied with direct reading gauge with a travel of 10 mm and an accuracy of at least 0.01 mm.
- It will also be supplied with reference bars of the approximate lengths of the test specimens.
- Vernier caliper of 300 mm and plastic dedicator of 300 mm diameter and one kg silica gel are the essential accessories to perform the test. Supplied at extra cost. See optional accessories.
NOTE :
ALSO NEED TO HAVE FURNACE TO COMPLETE THE TEST. THIS WILL BE SUPPLIED AT EXTRA COST.
Technical specification
|
Temperature Ranges |
5 °C above ambient to 100 °C |
|
Temperature Control |
Auto-Tune PID Digital Temperature Indicator cum controller with an accuracy of + 0.5 °C. |
|
Operates on |
230 Volts, 50 Hz, Single Phase, AC Supply |
|
Power Ratings |
4 KW |
|
Accommodate |
7 no test specimens of 100 mm (L) X 35 (W) mm |
|
Overall Dimensions |
885 X 480 X 650 (L X W X D) mm |
Accessories
CTM SOFTWARE WITH PC INTERFACE
Direct analytical reports on computer, Auto generation of load/time graph. Auto calculation of average of 3 readings, Two way communication facility - Can operate the machine through PC, Name of Issuing Lab and customer name can be inserted, Auto date and time of testing with age of testing (from the date of sample receipt), Transfer of result to PC on pressing ENT key. Results can be printed in EXCEL format. Data and design subject to change due to continuous R&D
SPLITTING TENSILE ATTACHMENT FOR CONCRETE CUBE AND PAVER BLOCK - BIS 516, BIS 15658, ASTM C496
This is an attachment to Compression Testing Machine. Compliance Standards, IS: 516 – 1959, IS:5816, IS: 1199-1959, SP: 23-1982, IS: 10086-1982, ASTM C496, BS1881, BIS 15658. Detailed specification mentioned in the long description.
LOAD FRAME FOR 500 KN - CTM AUTOMATIC-
This is an attachment to Automatic Compression Testing Machine of 1000 / 2000 / 3000 kN Capacity. The Pumping unit is shared by both the Load Frames. A valve is provided on the back of the Pumping unit to switch Flow of Hydraulic Oil either to 500 KN CTM Load Frame or to higher Capacity Load Frame. The attachment enable us test of Cement Cubes in addition to Concrete cubes without compromising the accuracy.
ELECTRONIC WEIGHING BALANCE-20 KG-1 GM-WITH INTERFACE TO CONNECT CTM
High Impact FRP Body, wide platform size 250 x 300 mm, with built in battery back up and with certificate of stamping from W&M department. Multi function and Auto calibration with external weight. We can also offer economic weighing balance having ABS body and small platform size of 200 x 250 mm.
