SAYBOLT VISCOMETER - REFRIGERATED

SAYBOLT VISCOMETER - REFRIGERATED

Model Number : TM-048RDMM

The Saybolt Viscosity Test determines the time required for 60 mL of bituminous emulsion to flow through a calibrated orifice under controlled temperature conditions. The result is expressed in Saybolt Furol Seconds (SFS). The viscometer can be used at 25°C or 50°C . The set up includes waterbath, motorized stirrer, Refrigeration system, electric heater with digital temp. controller with control accuracy of ± 0.1°C.


Complies with Following International Standards

ASTM D88 / IS:3117-2019, AASHTO T72/BS 2000-72


Applications

The Saybolt Viscometer is used to determine empirical measurement of Saybolt Viscosity of petroleum products at specified temperatures. The time it takes for a 60 ml sample to flow through a tube with a specified diameter (furol (3.150 mm) and universal (1.765 mm) ) is measured and reported in seconds. The viscometer can be used at any temperatures between 21 and 99 °C. The viscometer includes waterbath, motorized stirrer, Refrigeration system, electric heater with digital temp. controller with control accuracy of ± 0.1°C


Construction Details:

  1. The apparatus consists of stainless steel bath with two sample cup
  2. The bath has a lid which contains a thermometer socket and a straight heater.
  3. Temperature is controlled by PID Digital Temperature indicator cum controller
  4. Stirring is done by FHP motorized stirrer.
  5. A thermometer can be inserted into the cup cover to cross check the Digital controller.
  6. Two jets - one universal and one furol can be screwed to the cup by a handle.
  7. Entire assembly works on 220 Volt, 50 hz, Single phase, AC Supply


Supplied with following parts and accessories

  1. Universal Orifice : 2 pc
  2. Furol Orifice : 2 pc
  3. Thermometer Support : 2 pc
  4. Tube wrench : 1 set
  5. Stopper : 2 pcs
  6. Operation Instruction Manual : 1 Pc


The Following accessories are available at extra cost

  1. ASTM/IP Glass Thermometers
  2. Digital Stop Watch (Essential accessory)
  3. Withdrawal Tube
  4. Strainer for Filtering
  5. Flask - 60 CC (Essential accessory) - 2 Nos.



Overall Dimensions

800 X 400 X 700 (L X W X H) mm

Weight (Approx.)

`47.00 per unit
