LOW TEMPERATURE CIRCULATING CHAMBER-ONLINE CHILLER-1 TON-15°C TO 25°C

Salient Features:

• Double walled
• Highly efficient model
• Aesthetic outer appearance
• Easy operation and hassle free maintenance
• Automatically maintains the set temperature
• Portable online Chillers is popular among the customers for its instant results and smooth functioning.
• Complete with re-circulating unit for temperature uniformity
• Incorporates CFC Free refrigeration compressor
• Fitted with immersion heaters and compressor in order to maintain the set temperature
• Multi purpose unit useable for many other laboratory applications

Details

• Inner chamber consists of thick polished stainless steel with cooling coil duly soldered on the outside to ensure perfect cooling effect to achieve low temp. up to +5°C.
• The outer wall is of thick mild steel sheet duly pre-treated and powder coated for longer life.
• The hollow space between the inner chamber and outer wall is filled with high grade insulation of thickness 75 mm to prevent loss of temperature.
• The refrigeration system consists of Hermetically sealed compressor for minimum noise level and smooth operation, Coupled with other quality components, it ensures a high degree of reliability over a long period.
• Heating system comprises of immersion type heating element for attaining above ambient temperature.
• The unit is provided with a high performance circulation stirrer to circulate the inside fluid to ensure a constant and uniform temperature throughout.
• Temperature range 5°C to 50°C with PID digital temperature controller cum indicator.
