COLD CRUSHING STRENGTH APPARATUS - (ISO 4700, ASTM E382)- SERVO CONTROLLED - AUTOMATIC SPEED AND PACERATE CONTROLLED

COLD CRUSHING STRENGTH APPARATUS - (ISO 4700, ASTM E382)- SERVO CONTROLLED - AUTOMATIC SPEED AND PACERATE CONTROLLED

COLD CRUSHING STRENGTH APPARATUS-ISO 4700, ASTM E382- SERVO CONTROLLED - AUTOMATIC SPEED AND PACERATE CONTROLLED
Model No: None

Ref. Standard - ISO 4700, ASTM E 382. Determination of Cold Crushing Strength (CCS) of iron Ore pellet fired at different temperature. This machine is mainly used in crushing strength test for iron ore pellet. Detailed specification as follows:

 Main technical specification of Cold Crushing Strength (CCS) testing machine: .

  1. Fully computerized (auto stop after failure of the sample)
  2. Max. test force: 10 kN.
  3. Least count : 0.001 kN.
  4. Measuring range of test force: 0.1-10 KN.
  5. Accuracy of test force: ± 1%.
  6. Load indicator with facilities for displaying peak load value.
  7. The machine can run in 2 modes
  8. Speed controlled mode
  9. Stress controlled mode - Automatic pace rate control
  10. Speed Range 0.1 mm/min - 50 mm/min. with cross head speed indicator.
  11. Pace rate control from 1 kN / Sec to 10 kN /  sec
  12. Holds peak load at the failure point
  13. Kg and kN unit selectable
  14. 7" touch screen display
  15. Built in USB drive to transfer the data to computer
  16. Built in serial port to connect to printer directly (with out computer), you have to purchase printer separately.
  17. Precision Ball Screw drive system.
  18. Designed for testing CCS strength according to international standards.
  19. Suitable for operation on 220V, 50Hz, 1 Phase AC supply.
