Compliance standards
ASTM D256
Details
- Impact Energy :0-25 Joules
- Release angle of pendulum: 150°
- Micro controller: Setting of sample dimension, Error of machine and selection of Standard of test process (IS, ISO or ASTM), Hammer selection with Direct display of impact energy in joules & Impact Strength in J/mt & J/mt² And corresponding angle in degrees on digital indicator with selection of hammer.
- Hammers: Powder coated hammers for Izod tests for lowest scale would be supplied. Incremental plates would be supplied Which could be attached to these hammers to convert them in to hammers for 2nd, 3rd, 4th & 5th scale.
- Screw : (Vise) type powder coated bench for Izod test as per standard.
- 2 Line LCD display with 10 test memory with Average result of selected test.
- Indication to select Low or High value of Hammer during test.
- Indication to conduct test by microcontroller.
- Faulty sensor indication on LCD display.
- Easy, Safe and maintenance free release mechanism for Hammers.
- Easy interchangeability of hammers during test.
- Two Numbers Hammers supplying for IZOD & Charpy Test
- Two Wise for Conducting IZOD or Charpy Test
- Powder Coated Body Structure
OPTIONAL ACCESSORIES AT EXTRA COST:
1) Notch Cutter - Model: NOT – A.
- Manual Operated
- Depth Micrometer by wheel and resolution of 0.01 mm.
- Range: 0-25 mm
- L.C.: 0.01 mm
- Cutting Angle: 45 deg.
- Paint: Powder Coating
2) Notch Cutter - Model: NOT – B
- Motorized Operating.
- Depth Micrometer by wheel and resolution of 0.01 mm.
- Range: 0-25 mm
- L.C: 0.01mm
- Cutting Angle: 45 deg.
- Paint: Powder Coating
- Power: 230 V AC, 1 Phase, 60 Hz.
Capacity (Impact Energy) |
0-25 Joules |
Release angle of pendulum |
150° |
Range of Four Scale |
0-2.71 Joules |
0-5.42 Joules |
|
0-10.84 Joules |
|
0-21.68 Joules |
|
0-25 Joules |
|
Scale Resolution |
0.02 Joules |
0.05 Joules |
|
0.1 Joule |
|
0.2 Joule |
|
0.2 Joules respectively. |
|
Paint |
Powder Coated |
Power Supply |
230 V AC, 1 Phase, 60 Hz |
