DROP POINT APPARATUS FOR PARAFFIN WAX - ASTM D3954 - FULLY AUTOMATIC

Model Number : EIE-PTLT-110FA

None

More Information

Compliance with following International Standards:

ASTM D3954

Purpose:

This instrument is suitable for detecting the dropping point of all non-liquid waxes including paraffin wax, microcrystalline wax, polyethylene wax, blended wax and natural wax.

Summary of test method

In this test method, the dropping point is defined as the temperature at which the wax suspended in a cylindrical cup. with a 2.8-mm dipmeter hole in the bottom, flows downward a distance of 19 mm to interrupt a light beam as the sample is heated at a constant rate in air.

Apparatus Details:

The complete test assembly consists of following parts & accessories

1) Grease Cup:

A chromium-plated brass cup conforming to ASTM Standard D566

2) Test Tube:

A test tube of heat-resistant glass with rim,
100 to 103 mm in length
11.1 to 12.7 mm in inside diameter
Provided with three indentations about 19 mm from the bottom, equally spaced on the circumference.

3) Thermometers:

Temperature range : -5 to 300 C
Thermometer Number : ASTM 2C / IP 62C

4) Cork for test tube:

Cover for test tube

5) Brass rod (Metal Rod):

1.2 - 1.6 mm in diameter
150 - 152 mm in length

6) Heating device (Magnetic Stirrer With Heater):

Totally enclosed unit
Easy to use & clean
Designed for use even in corrosive atmosphere
Fully automatic heating cum magnetic stirring device with sample detecting sensor
Touch screen HMI & Programmable PLC Controller
Fully guided and automated on screen instructions
Last 10 readings can be stored and viewed in the touch screen controller
Saved reading can be transferred to computer in excel file through USB port.
Better speed regulation even with small volume and low speeds
Accurate stepless speed control THROUGH HMI Touch Screen maintains excellent speed stability.
Consist of 400 ml glass beaker as oil bath
Beaker is placed on the top surface of the magnetic stirrer and bath temperature is raised to 20-25°C below the expected drop point of grease.
Supplied with PTFE coated stirring paddle 9 X 25 mm
Temperature Accuracy : ± 1 °C
Sample Stirring Capacity : Max Volume 1000 Ml (Water)
Max. Stirring speed : 1200 RPM
Heating Surface Plate Dim : 135mm X 135mm
Heating plate material : Stainless Steel
Max Temperature Range : 400° C
Power Requirements : 220 Volt, 50 Hz, Single Phase, AC Power supply
