COMPRESSION TESTING MACHINE - 250 KN-DIGITAL - MANUAL PACE CONTROL

Compliance with following International Standards:

 IS  :  14858 ‑ 2000 and IS 516

Introduction:

The digital compression testing machine has been designed to meet the need for a simple, economic and reliable means to test concrete for its compressive strength.

The design expressive of simplicity, both of construction and operation, makes the machine easy to use and maintain.

The digital machines are provided with a MANUAL pace rate controller, to enable maintain a constant rate of loading.

Salient Features of EIE ‑ Digital CTM Machine:

1. 2 line Alphanumeric display with backlite, displaying ‑ Actual Load / Peak load, Rate of loading and Calculated load in N/mm² (as soon as sample fails)
2. Four column high stiffness and high stability fully welded construction of the load frame.
3. Direct reading of compressive strength in N/mm2 ‑No calculation required.
4. Peak hold facility.
5. Can manually control pace rate from 1 KN/Sec to 20 KN/sec.
6. Pace rate indication in KN/Sec.
7. Bar Graph indication to control the pace rate
8. Built in memory for last 10 readings
9. Automatic internal calibration(without Proving ring)
10. Safety cut out for overload and electrical short circuit.
11. Safety door on the front side for operator safety.
12. Compact Pumping unit with manually variable rate of loading.

Scope of supply:

1. High strength rigid structure (Loading Frame)
2. Pumping unit (Oil source cabinet)
3. Digital Load indicator
4. High precision pressure transmitter
5. Pair of compression platens
6. High pressure hose pipe

Note :

Use of 3 KVA three phase servo controlled stabilizer is essential to protect the machine against voltage fluctuations. Warranty voids in case of any damage due to power fluctuation.
